KWO®CellFlon®Sheet Blue is a gasket sheet material containing structured PTFE and hollow glass micro-spheres.
KWO®CellFlon®Sheet Blue is especially for use in applications where the available bolt load is limited or uneven or damaged flange connections.
Suitable for sealing most chemicals across the whole pH range (0-14), including moderate concentrations of acids and caustics, solvents, hydrogen peroxide or refrigerants.
TECHNICAL DATA
MATERIAL
structured PTFE with hollow glass micro-spheres
CHEMICAL RESISTANCE
in the entire pH range (pH 0-14, except molten alkali metals or elemental fluorine)
TEMPERATURE RANGE
recommended temperature range: from -210°C (-346°F) to +260°C (+500°F), material heat resistant up to +315°C (+600°F)*
PRESSURE RANGE
vacuum up to 55bar (800psi) depending on the installation situation*
PHYSIOLOGICALLY INERT
physiologically harmless in all recommended applications
DENSITY
1,40 g/cm³ ± 0,25 g/cm³
*NOTE: temperature and pressure guides cannot necessarily be used simultaneously.
